ISUZU Truck - QMR77HE5A - Chassis

OVERVIEW

model ISUZU Truck - QMR77HE5A - Chassis

Gross Vehicle Mass	4,990 (KG)
Overall Dimension	5,915 x 1,860 x 2,240 (mm)
Max. Power	120(88) / 2,900 (Ps(kW) / rpm)
Emission Standard	EURO 5
Manufacturers Name	Isuzu Vietnam Co., Ltd
Manufacturers Address	695 Quang Trung Street, Ward 8, Go Vap District, Ho Chi Minh City
Origin	Vietnam
Suggested retail price	595,080,000 VNĐ

download brochure

ENGINE

UPGRADED ENGINE MORE POWERFUL

HI-PRESSURE COMMON RAIL EURO 5 SYSTEM

Exterior

HIGH EFFICIENCY FRONT HEADLAMP

WIDE MONITOR-FIELD REAR VIEW MIRROR

100 LITERS FUEL TANK

Interior

SPACIOUS AND CONVENIENT INTERIOR

MANY USEFUL STORAGE & CUP HOLDERS

JAPANESE STANDARD AIR CONDITIONER SYSTEM

POWER WINDOW AND CENTER DOOR LOCK

specification

MASS

DIMENSIONS

ENGINE & TRANSMISSION

PERFORMANCE

BASIC SYSTEMS

EQUIPMENTS

Gross Vehicle Mass	Kg	4,990
Kerb Mass	Kg	1,955
Number of Seats	Person	03
Fuel Tank	Liter	100

Overall Dimension OL x OW x OH	mm	5,915 x 1,860 x 2,240
Wheelbase (WB)	mm	3,360
Front – Rear Tread (AW – CW)	mm	1,398 / 1,425
Ground Clearance (HH)	mm	210
Front – Rear Overhang (FOH – ROH)	mm	1,095 / 1,460

Model		4JH1E5NC
Type		Common rail, turbo – intercooler
Emission Standard		Euro 5
Displacement	cc	2,999
Max. Power	Ps(kW) / rpm	120 (88) / 2,900
Max. Torque	N.m(kgf.m) / rpm	290 (30) / 1,500~2,900
Transmission		MSB5K 5 Forward & 1 Reverse

Max Speed	Km/h	94
Gradeability	%	41
Min Turning Radius	m	6.7

Steering System	Recirculating ball with hydraulic assisted
Suspension System Front – Rear	Dependent, leaf springs, shock absorber
Brake System Front – Rear	Drum, hydraulic with vacuum servo assistance, dual circuits
Tire Size Front – Rear	7.00-15 12PR
Generator	14V-60A/ 14V-90A
Battery	12V-80(AH) x 01

2 Sunvisors for driver and co-driver.
Power windows & Central door lock
Inside guard bar
Cigar lighter
Air conditioner
3-point seat belt
Reversing warning buzzer
Cooler and defroster
USB-MP3, AM – FM radio
Data recording module
Tilt cab warning buzzer
