FVR34LE4 (4x2)
| MAIN SPECIFICATIONS | ||
|---|---|---|
| Overall OAL x OW x OH | mm | 6790 x 2485 x 2970 |
| wheelbase | mm | 4300 |
| Gross vehicle weight | kg | 16000 |
| Payload | kg | 8150 |
| Engine | 6HK1E4NC | |
| Engine type | 4 stroke, In-line 6 cylinders Common rail, turbo-intercooler | |
| Displacement | cc | 7790 |
| Max Output | Ps(kW)/rpm | 241(177) / 2400 |
| Max Torque | N.m(kgf.m)/rpm | 706(72) / 1450 |
| Tire size (Front / Rear) | 11.00R20 / 11.00R20 | |
| Seating Capacity | person | 3 |
| SPECIALIZED SYSTEM | ||
| Rear body displacement | 6,7 m3 | |
| Rear body structure | Reinforce panel outside rear body wall | |
| Material | alloy steel | |
| Tailgate | 01 tailgate, open/close automatically when lifting rear body | |
| Rear body lift control | Manual, control lever inside cabin | |
| Hydraulic system | Imported | |
